High Current NTC Thermistor Temperature Sensor with Operating Temperature -40℃~+120℃ and R25 500Ω~5MΩ for Disinfecting Cabinet

Name: High Current NTC Thermistor Temperature Sensor with Operating Temperature 40120 and R25 500Ω5MΩ for Disinfecting Cabinet
Brand: HENG HAO
Price: 0.18 USD

China High Current NTC Thermistor Temperature Sensor with Operating Temperature -40℃~+120℃ and R25 500Ω~5MΩ for Disinfecting Cabinet factory

Place of Origin : China

Brand Name : HENG HAO

Model Number : NTC Thermistor

MOQ : 5000

Price : $0.18-0.25

Operating Temperature : -40℃~+120℃

Nominal Resistance : 500Ω~5MΩ

Resistance Tolerance : ±1,±2, ±3, ±5, ±10

Material Coefficient : 2500~5000K

Thermal Sensitivity : Constant temperature 50℃±0.05℃

Dissipation Coefficient : ≥0.8mw/℃

Thermal Time Constant : ≤25S

Rated Power : 50mw

Package Type : Surface Mount

Technology : Metal Alloy

Resistance Range : 500Ω~5MΩ

B25/50 Tolerance : ±1,±2

Static Air Condition : Static in the air

Working Temperature : -40℃~+120℃

Thermal Resistor Type : NTC Thermistor

Contact Now

Products Description

R25(nominal resistance value)	500Ω~5MΩ, Constant temperature 25℃±0.05℃
R25 Permissible variance(%)	±1,±2, ±3, ±5, ±10,Constant temperature 25℃±0.05℃
B25/50 (material coefficient)(thermal-sensitivity index)	2500~5000K, Constant temperature 25℃±0.05℃ Constant temperature 50℃±0.05℃
B25/50 Value permissible variance(%)	±1,±2, Constant temperature 25℃±0.05℃ Constant temperature 50℃±0.05℃
∫(dissipation coefficient)	≥0.8mw/℃, Static in the air
T(thermal time constant)	≤25S,Static in the air
Ta(Working temperature)	-40℃~+120℃
Pn (rated power)	50mw,within working temperature
Used for	Applicable for temperature measurement and control of induction cookers, irons, electric barrettes, water heater, drinking machine, warm air blower, dishwasher, disinfecting cabinet, washing machine, drying machine, medium and low temperature drying box, constant temperature box
